| Model | CSV-CD12 | CSV-CD16 | CSV-CD24 |
| PV Array input | ≤12 | ≤16 | ≤24 |
| Analog input | 1 channel, 4-20mA/0-5V | 1 channel, 4-20mA/0-5V | 1 channel, 4-20mA/0-5V |
| Digital input | 2 channel, passive dry contract | 2 channel, passive dry contract | 2 channel, passive dry contract |
| Communication port | 1*RS485, 2500V photoelectric isolation | 1*RS485, 2500V photoelectric isolation | 1*RS485, 2500V photoelectric isolation |
| Communication lighting protection | 4KV(10/700us)(GB9043-1999) | 4KV(10/700us)(GB9043-1999) | 4KV(10/700us)(GB9043-1999) |
| Digital display | Accurate to 0.01 error≤5% | Accurate to 0.01 error≤5% | Accurate to 0.01 error≤5% |
| Power supply | 85-264V ac or 120-370V dc or 18-36V dc | 85-264V ac or 120-370V dc or 18-36V dc | 85-264V ac or 120-370V dc or 18-36V dc |
| Power | ≤10W | ≤10W | ≤10W |
| Working temperature | -35ºC to +70ºC (-30ºF to +158ºF) | -35ºC to +70ºC (-30ºF to +158ºF) | -35ºC to +70ºC (-30ºF to +158ºF) |
| Storage temperature | -40ºC to +85ºC (-40ºF to +185ºF) | -40ºC to +85ºC (-40ºF to +185ºF) | -40ºC to +85ºC (-40ºF to +185ºF) |
| Humidity | 5-95% no condensation | 5-95% no condensation | 5-95% no condensation |
| Fast transient burst | GB/T17626-4-4 class 3 | GB/T17626-4-4 class 3 | GB/T17626-4-4 class 3 |
| Surge immunity | GB/T17626-4-5 class 3 | GB/T17626-4-5 class 3 | GB/T17626-4-5 class 3 |
| PDMF | GB/T17626-4-5 class 4 | GB/T17626-4-5 class 4 | GB/T17626-4-5 class 4 |
| Width*height*depth | 317mm*44mm*80mm | 360.5mm*41mm*88.2mm | 317mm*44mm*88mm |
| Installation | Backplane wall mount | Backplane wall mount | Backplane wall mount |
